Promotion Price Pet Animal Microchip Scanner
TP-A03 is a handheld low-frequency tag reader with128*64 high-light OLED screen,which adopts wireless reading method and supports electronic tags in EMID, FDX-B (ISO11784/85) formats,has the function of database management the animal codes and operating details can be transmitted to PC through USB or wireless transmission. Besides, statistics can be uploaded by the reader can be changed into formats including word, excel, and other cursor points. By this way, clients can take the reader as a data collection and timely transmission machine.
More Detail about RFID Microchip Reader
Model | TP-A03 |
Operating frequency | 134.2Khz/125Khz |
Tag format | EMID, FDX-B(ISO11784/5) |
Read & write distance | 2*12mm Glass Tube Tag>15cm: 30mm Animal Ear Tag>25cm |
Handheld device size | 28cm*14.7cm*6cm |
Reading range | <100ms |
Signal indication | 128*64 high-light OLED, hummer |
Power supply | 6.7V lithium battery(three 5th battery), charge mode: USB interface |
Power consumption | operating mode: 0.9W; standby mode: 0.3W |
Storage capacity | 6000 items (tag code & time) |
Storage time | more than 20 years |
Communication interface | USB2.0,Bt |
Weight | 300g (without batteries) |
Operating temperature | -10℃~50℃ |
Storage temperature | -30℃~70℃ |
